1. Overview
SC Fast Connect allow you to terminate a fibre in short time. The fast connect is a prepolished connector
which uses mechanical clamping andaligning of a cleaved fibre end which is inserted into the connector
body.The fast connect is available in both singlemode and multimode (OM1 and OM3 10Gig)and a variety
of connector types and can be terminated onto 250μm and 900um coated fibre as well as 2 x 3 mm and
2x1.6 mm jacketed cord.
2. Features
2.1 Field-installable
2.2 Fast and easy to terminate
2.3 Excellent insertion and RL performance
2.4 Reusable
2.5 No termination enclosure required
2.6 Handles and performs like a factory terminated connector
3. Application
3.1 Direct termination of fibr
3.2 FTTx networks(FTTH、FTTD)
2.7 Twin end-face of pre embedded fiber is polised in the factory
2.8 Fiber optics is aligned in V-groove through the ceramic ferrule
3.3 Enterprise/Access network
3.4 L AN/WAN
3.5 Permanent/Temporary replacement/repair
3.6 Pre-installation cable drum testing
